Century Split-Phase Belt Drive Motor, 1/2 HP, 1701-1800 RPM Range 115V, CWLE

Energy-efficient motor features extended studs for mounting fan guard on shaft endshield. Designed as a replacement for OEM motors used in Triangle belt-drive exhaust fans. For use in exhaust fans, air circulators, and other air-over fan applications. Open motors are for use in clean, dry, nonhazardous locations.

OEM Replacement Brand: Triangle Engineering
Item: Belt Drive Motor
Motor Design: Split-Phase
Phase: 1
HP: 1/2
RPM Range: 1701-1800
No. of Speeds: 1
Voltage: 115
Motor Shaft Rotation: CWLE
Frame: 56Z
Motor Enclosure Design: Open Dripproof
Motor Mounting Type: Rigid Base
Shaft Dia.: 1/2"
Shaft Length: 1-1/2"
Number of Shafts: 1
Motor Thermal Protection: Auto
Nameplate RPM: 1725
Motor Application: OEM Replacement
Motor Sub Application: Belt Drive Fan/Blower
Full Load Amps: 8.0
Hz: 60
Ins. Class: B
Max. Ambient Temp.: 40 Degrees C
Motor Service Factor: 1.00
Motor Bearings: Ball
Body Dia.: 6-1/2"
Length Less Shaft: 7-7/16"
Overall Length: 8-15/16"
Capacitor Required: No
Replacement For: Triangle Engineering SPL4213 fan motor: PMTR-SPL4213_A, S56C23A97, S56A09A97, S56A03A97, S56A19A97, S56A62A97, S56A33A97, 320P551, 316P760, 5K36JNA769X, 5K36JNA984X, 5KH36JNA984X, S63NXJDC7562, S63NXSMT-7035, YQC56S17D323B, YQE56S17D318E, HG2K012K, HE2H127N, S55NXNFJ-7059, S55NXPKL-7622, 3WH56A1708AP, 4WE56A1709AP, 4WE56AZ1709AP,YQDS56S17D323BP, 26G89525A,3YH56A1708A-P, XQC56S17D318D, YQD56S17D323B, YQD56S17D318E 320P526, S56A72C22, 4WD56A1709AP, 4YD56AZ1709AP, 4VE56A1709AP,XQD56S17D318D, 3VL56A1708A-P, XQE56S17D318D, 056S17D318D, YQD56S17D318D, S55AXNMZ-7208,S63NXJDC-7562,637562
Application: Replacement Motor for Triangle Engineering Exhaust Fan
Standards: UL Recognized, CSA Certified
